Box Beam Roll Forming Machine

Product Descriptions

Box Beam is manufactured from two tensile steel C-shaped sections, joined by a Box Seaming Machine to form a strong beam but very lightweight.

Version to design

Working flow

Decoiler ---- Levelling--- Roll Forming ---- Cutting ---- Run out table—Boxing

Technical parameters

Machine specification

· Electric power 7.5 kW-15 kW

· Rolling speed 14-16 m/min (including cutting and punching process)

· Machine Weight 8.0-12 tons

· Dimensions (L x W x H) (8-10) m x 1.4 m x 1.6 m

· Station quantity 16-18 stations

· Cutting and punching equipment “1. Entrance shearer : 01 set
2. Exit shearer : max 12 sets”

Raw material

· Steel Thickness 1.2-3.0 mm BMT

· Material Strength G450

Production specification

· Control System PLC, Touch Screen HMI

· Rolling transmission Gear motor driven by Inverter

· Cutting and punching system Hydraulic

· Length Tolerance ± 2.0 mm

Machine components

• Hydraulic Decoiler
• Forming machine
• Cutting device
• Punching machine
• PLC control box
• Hydraulic pump station
• Hydraulic punching device
• Production support table

Machine pics
